2PCS H Bridge Remote Control 5A 3V-14V Dual DC Motor Controller Drive Module Voltage Reverse PWM Speed Regulation Double

KWD 3.500
KWD 4.500
Brand
GODIYMODULES
Weight
31 g
– 1 +

Special Features

  • 2PCS H Bridge Remote Control 5A 3V-14V Dual DC Motor controller Drive Module Voltage Reverse PWM Speed Regulation Double
  • Two motors can be independently controlled, each channel can output 5A, peak 9A, standby current is only 10uA;
  • Wide voltage range of 3-14 v, signal voltage range of 2.2-6 v, 3.3 v and 5 v levels can be satisfied;
  • The board provides 3.3v 100ma power supply to the power consumption of your operating system
  • Two-way H-bridge motor drive, can drive two DC motors or a 4-wire two-phase stepper motor at the same time;
  • the input voltage is 2.2-6 v, support 3.3v and ttl level;
  • Single working current is 5A, peak current can reach 9A, low standby current (less than 10uA);
