Transformers
Applicable: DAC, headphone amplifier, preamp, small power amplifier, CD player, etc.
Dimensions: Length 79mm Width 68mm Height 40mm Weight: 0.55kg
4 mounting screw holes on the base
Center shaft hole distance: 45mm X 55mm
Input voltage: (international voltage ~ global universal!)
0-115V, 0-115V , shielded wire (total 5 wires)
18V-0V-18V (0.5A3 wire)
0-9V(0.3A), 0-9V(0.3A), 0-9V(0.3A), 3 groups (6 wires)
Description: 220V voltage connection: red and brown connected to 220V
The voltage can be measured only when the yellow and blue are combined and then short-circuited (that is, two wires are short-circuited).
