Product description:
Manual reset circuit breaker 50A
Rated voltage: 6-28V
Rated current: 50A (5-50A available)
Suitable for 6-28V DC applications
Manual reset button (on the Bat side)
Plastic body and mounting bracket
Termination: Two #10-32 tread studs; 0.66" (AUX) x 0.56" (BAT)
#10-32 bolt length :37 inches; bolt spacing:69 inches
Interruption rating: 2.5KA @ 12Vdc
Operating Temperature Rating: –40°F (–40°C) to 185°F (85°C)
Storage Temperature Rating: –40°F (–40°C) to 260°F (125°C)
Marking: Standard marking includes Amp Rating and date code
Torque rating: 15in-lb
Compliances: SAE J553; SAE J1171 (Ignition Protected)
Black UL rate 94V0 thermoplastic body with gray cover thermoplastic
Applications: battery chargers, stereos, cars, trucks, buses, ships, recreational vehicles, trailer motors, etc.

Package Included: 3x 50A Resettable Circuit Breaker
