Dorhea 0.96 inch OLED i2c Display Module IIC Serial LCD Screen 0.96" LED Module Display Yellow Blue 12864 OLED /3.3V-5V 128 X 64 Compatible with Nano Display Raspberry Pi 51 Msp420 Stim32 SCR Blue

KWD 2.500
Brand
DORHEA
Weight
46 g
ColorBlue
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.
– 1 +

Special Features

  • This OLED display module is 0.96 inch diagonal,Resolution: 128 x 64, View angle: > 160°, Support voltage: 3.3V-5V DC, Power consumption: 0.04W during normal operation, full screen lit 0.08W,Color:White Light
  • Embedded Driver IC: SSD1306, Communication: I2C/IIC Interface, only need two I / O ports.This oled display can be used with different machine easily
  • 0.96 inch oled module for showing graphical & textual information directly on your micro-controller projects. It compatible with Mega, Raspberry pi, 51 MCU, STIM 32
  • Needn't backlight, the display unit can self-luminous. It has Super high contrast, bright and crisp dots, even tiny fonts quite readable
  • No embedded fonts inside the OLED controller, user can create the fonts through the font generation software

Description

Size: 0.96
Resolution: 128X64
Color: White
Viewing angle: greater than 160 degrees
Supported platforms: 51 series, MSP430
series, STIM32 / 2, SCR chips
Low power consumption: 0.04W during normal operation Support wide voltage: 3.3V-5V DC
Working temperature: -30-80 degrees
Driver IC: SSD1306
Communication: IIC, only two I / O ports
No font: The software takes word modulo
Backlight: OLED self light, no backlight Interface
VCC: 3.3-5V GND: Ground
SCL: Serial Clock
SDA: Serial Data

Applications:
MP3, MP4, watch
Head-mounted displays
Meters and other intelligent instruments
Design any pretty patterns for your beloved electronic devices!

Package Included:
6 X 0.96'' OLED display module
6 X plastic containers
