This device allows you to safely and remotely kill your electronic ignition equipped engine from your transmitter. This kill switch is Fiber Optically Coupled to isolate your ignition system from your radio system. (No Interference!!)

Compatibility Devices
DLE20/DLE30/DLE35 RA/DLE55/DLE55 RA/DLE60/DLE111/DLE170/DLE222 and AGM30/AGM60 gas engines

Specification
* Brand: Rcexl
*Material: metal + plastic
* Model: Opto Gas Engine Kill Switch
* Type: Version 2.0
* Input battery: Li-Po, Li-ion, A123, Ni-Mh, NiCad
* Output current: 3V 3A / 20V 16A

Features
* Include a mountable LED indicator once start ignition
* Fiber Optic conpled input/output
* PIC12F675 Controller
* Low Voltage Drop-Less than 150mv.
* Low to 3V 3A output
* Up to 20 Volt 16 amp MOS-FET (IRF7456) output.
* Reverse Battery input protection.
* Pure Surface Mount Technology
* Universal connectors with heavy gauge wires
* Can automatically cut off by turn off the transmitter power
* Shut down the transmitter power or receiver to cut off automatically
*This device allows you to safely kill your engine at anytime(on the ground, or in the air!)

Note
*This switch does not have BEC function (BEC: Battery Eliminator Circuitry)
*Do not touch grease or water or corrosive materials when installing

Package
1 x Opto Gas Engine Kill Switch V2.0
