The SWIFT-LCD-20 is a professional-grade 2.0-inch full-color TFT LCD display module designed for high-performance embedded applications. Featuring a crisp 240x320 resolution and IPS wide-viewing technology, it delivers stunningly clear visuals and vibrant colors from any angle. Whether you are building a smart wearable, a custom dashboard, or an interactive IoT node, this module provides the reliability and visual impact your project deserves.
Key Advantages
Exceptional Clarity: With 240*320 pixels packed into a 2.0" screen, enjoy high pixel density for smooth text and sharp graphics. The IPS panel ensures no color inversion or blurring even when viewed from extreme angles.
Simplified Integration: Internal pull-up resistors for RES (Reset) and BLK (Backlight) pins mean fewer wires and faster setup. It's ready to light up as soon as you connect power and SPI data.
Versatile Compatibility: Supports a wide 3.3V-5V power supply, making it plug-and-play with Arduino, ESP32, Raspberry Pi, and STM32 platforms.
Technical Specifications
Screen Size: 2.0 Inch
Resolution: 240 x 320 Pixels
Driver IC: ST7789
Interface: 4-Wire SPI
Operating Voltage: 3.3V - 5.0V
Supply Current: 80mA (Typical)
Viewing Angle: Full View (IPS)
Operating Temp: -20°C to +70°C
Module Size: 56mm x 40mm
Pin Interface Definitions
G (GND): Ground
V (VCC): Power Supply (3.3V-5V)
SCL: SPI Serial Clock Input
SDA: SPI Data Input/Output
DC: Data/Command Selection
CS: Chip Select (Active Low)
(Note: RES and BLK pins are pre-configured internally for ease of use.)
Package List
2x SWIFT-LCD-20 Display Module
2x GH1.25 to Dupont 6-Pin Anti-reverse Cable
