Features:
*Advanced Motion Tracking: The BNO085 IMU integrates a high-performance 9-axis system, providing exceptional motion tracking capabilities that enhance augmented reality (AR), virtual reality (VR), and robotics applications with precise data.
*Compact Design: This sensor module features a small factor, making it for IDEAL for integration into a wide range of IoT devices without sacrificing performance, enabling seamless incorporation into various projects.
*Low Power Consumption: Powered by a 32- ARM Cortex M0+ MCU, the BNO085 is designed for efficiency,long operational life in -powered devices while delivering robust performance for complex calculations.
* Comprehensive Sensor for fusion: Leveraging sensor hub software, it fuses data from the accelerometer, gyroscope, and magnetometer to provide precise orientation and motion for insights, minimizing for Drift for reliable performance.
*Versatile Interface Options: The BNO085 supports I2C, for SPI, and UART interfaces, providing flexible connectivity options for easy integration into different platforms and allowing developers to implement it in a variety of applications effortlessly.

Specifications:

*Part Name: 9DOF Sensor Module
*Material: None
*Size: 25.8*15.5mm
*Color: Purple
I2C (default): Up to 400kHz
for SPI: Up to 3MHz
UART: 3Mbps
UART-RVC (Robot Vacuum Cleaner): 115200kbps
Dynamic Error: 3.5°
Static Error: 2.0°
Game Rotation Vector
Dynamic Error: 2.5°
Static Error: 1.5°
Heading for Drift: 0.5°/minute
Geomagnetic Rotation Vector
Dynamic Rotation Error: 4.5°
Static Rotation Error: 3.0°
Gravity Angle Error: 1.5°
Linear Acceleration Accuracy: 0.35m/s²
Accelerometer Accuracy: 0.3m/s²
Gyroscope Accuracy: 3.1°/s
Magnetometer Accuracy: 1.4μT

Package Content:

1*Module
1*Pin header
