Resistor Networks
Electrical Specification 1.0
Nominal impedance: 50 ohms
Frequency range: DC 10.0 GHz
Standing Wave Ratio: DC - 4.0 GHZ Maximum 1.12:1 4.0-10.0 GHz Maximum 1.40:1
Input power CW: 10 watts @ 100°C heat sink, derated linearly to zero power and 150°C
Peak power: 100 watts (based on 10us pulse width and 1% duty cycle)
DC resistance: 50±5%
