High Pass
DL-3DB1
3A
250V AC
≥500MΩ
≤0.5mA

DL-6DB1
6A
250V AC
≥500MΩ
≤0.5mA

DL-10DB1
10A
250V AC
≥500MΩ
≤0.5mA
Technical Specifications
Rated Voltage
250VAC
Operating Frequency
50/60Hz
Rated Current
1-10A
Test Voltage(1min)
1500VDC Line/LINE
1750VAC Line/Ground
Climate Category
25/085/21
Schematics
Outline Drawing & Dimensions
