Operational Grade 1 Certified: ANSI/BHMA A156.13, Series 1000
Fire Resistance: UL/cUL Rated Up to 3 Hours
Windstorm Compliance: Certified, Check Local Codes
Durable Mechanism: Stainless Steel
Backset Measurement: 2-3/4 Inches
Latchbolt: 3/4 Inch Stainless Steel Throw
Door Thickness: 1-3/4 to 3-1/4 Inches, Special Orders Available
Front Design: Bevel Front, Adjustable from Flat to Standard Bevel
Cylinder Details: Brass, 6-Pin, Keyed-Random with Two Keys, 7-Pin Available
Handing Reversibility: Field Reversible
Strike Configuration: 1-1/4 Inch Curved Lip, Special Orders Available
Finish Options: 17 Finishes Available
Warranty Coverage: 10 Year Mechanical
Description
Electrified Mortise Lock, Fail-Safe, 12V, Without Cylinder, PNCN Trim, Satin Brass. Yale's 8800 Series Mortise Locks are engineered for robust strength and longevity across various commercial settings. Installation is simplified with swift lever adjustment, reversible latchbolt in the field, and standard non-handed strike. This series boasts enhanced security with a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim, and ANSI/BHMA Grade 1 certification for extended durability.
