High Precision Roughness Tester, Portable Roughness Gauge, Memorize 7 Sets of Measurement Data, Measures Ra, Rz, Rq, Rt, Auto Shutdown, for Accurate Surface Measurement in Kuwait High Precision Roughness Tester, Portable Roughness Gauge, Memorize 7 Sets of Measurement Data, Measures Ra, Rz, Rq, Rt, Auto Shutdown, for Accurate Surface Measurement in Kuwait High Precision Roughness Tester, Portable Roughness Gauge, Memorize 7 Sets of Measurement Data, Measures Ra, Rz, Rq, Rt, Auto Shutdown, for Accurate Surface Measurement in Kuwait High Precision Roughness Tester, Portable Roughness Gauge, Memorize 7 Sets of Measurement Data, Measures Ra, Rz, Rq, Rt, Auto Shutdown, for Accurate Surface Measurement in Kuwait

High Precision Roughness Tester, Portable Roughness Gauge, Memorize 7 Sets of Measurement Data, Measures Ra, Rz, Rq, Rt, Auto Shutdown, for Accurate Surface Measurement

KWD 449
– 1 +

Special Features

  • 【High-Precision】Provides measurement accuracy up not more than ±10%, ensuring accurate surface roughness and profile height measurement results to meet industrial-grade needs.
  • 【Metric And Imperial Unit Conversion】The flexible unit conversion function allows users to easily switch between metric and imperial to adapt to different measurement habits and application scenarios.
  • 【Multi-Function Data Output】Connect to the computer through the USB Interface data output, facilitate data transmission and storage, and improve data management efficiency.
  • 【Portable Design】Compact and lightweight integrated design, easy to use, intuitive reading, suitable for quick measurement and portable use on site.
  • 【Application】It is widely used in shot blasting, sandblasting, printing, spraying anti-corrosion, machining, including flat, inclined, outer cylindrical surface holes, grooves, axles and other metal and non-metal flat and uneven surface detection.

Description

Product Parameters
Measuring Range: Ra、Rg: 0.005~20.00 um, Rz, Rt: 0.020-200.0 um
Accuracy: Not more than ±10%
Fluctuation of display value: Not more than 6%
Resolution:
0.001μm, when the measured value is 0.01μm, when the value measured by 10ums is less than 100μm
0.1μm, when the measured value is ≥100μm
Sensor radius: 10μm
Sensor materials: Diamond
Measurement Force: 16mN(1.6gf)
Angle: 90°
Vertical Radius: 48mm
Maximum Driving Stroke: 17.5mm/0.7inch
Select memory function: 7 groups
Power supply: Built-in lithium battery
Size :140x52x48 mm
Weight: 420g

Product Include
Host machine *1
