Maximum Ratings
Ua--------------------------------1500V
Pa-----------------------------125 W
Recommended operating conditions (reference values)
Class B (AF) double barrel
Typical operating limit parameters
Ua------------------ 1250 1500 1250 V
Ia (mAx.sig per tube) -------------------- 210 mA
Pa (in) (mAx.sig per tube) --------------- 315 W
Pa (per ton---------------------------- 125 W
UG ---------------------------------- -16 V
Ug(pk)------------- 235 280 V
Ia (0)----------------- 148 84 mA
Ia (mAx.sig) ---------- 500 600 mA
Pd(mAx.sig)--------------------- 6 7 W
RL(aa)-------------- 6.7 8.2 K
Output power (mAx.sig) -------------- 300 370 W
