Preamps
6SN7-SE
Medium U dual transistor, used in voltage amplifier circuit. 6SN7GT, 6SN7C, 6SN7 can be directly used to replace 6N8P
Hot line voltage
Ultra high 6.3 volts
0.6A current
Static parameters
Voltage 90 250 V
Voltage 0 -8V
Current 109 mA
On resistance3 2.6 mA/V
6.7 7.7 thousand
20 20
When Ug=-12.5V, Ia_1.3mA
When Ia=-10uA, Ug is -7-18V
Final Rating
Class A1 amplification (each side)
450 volts
Current - 20mA
Pascal
Pa (No. 1+No. 2) 7w
Type 1M
Rated voltage ±100V
