Filter Valves
Temperature setting range: 40-45
Cold and hot water inlet temperature range: 4-95
Maximum working temperature: 99℃
Temperature stability: +/-2 ℃
Working pressure: 0.03-1Mpa
Ideal working pressure: 01-0.5Mpa
Three-way valve: two outlets, one inlet
1. Technical data
G1/2"
A. Maximum operating temperature: 99
b. Rated outlet flow at 1 bar pressure drop: 11.67L/Min
Other sizes have different flow rates.
2. Structural materials
A. Valve body: brass nickel plated
b. Shutter: PPO
C. Connection method: inlet-external thread, outlet-external thread
