ConfigurationSingle
Direction TypeBi-Directional
Number of Elements per Chip1
Minimum Breakdown Voltage (V)44.7
Maximum Clamping Voltage (V)64.8
Maximum Reverse Stand-Off Voltage (V)40.2
Maximum Peak Pulse Current (A)23.5
Maximum Reverse Leakage Current (uA)1
Test Current (mA)1
Peak Pulse Power Dissipation (W)1500
Minimum Operating Temperature (°C)-55
Maximum Operating Temperature (°C)175
Maximum Power Dissipation (mW)6500
Product Weight (g)1.2
PackagingTape and Reel
Diameter5.3(Max)
Mounting Through Hole
Package Length9.5(Max)
PCB changed 2
Standard Package Name DO
Supplier Package DO-201
Pin Count 2
Lead Shape Through Hole
