SX460 AVR Pressure Regulator
1. Introduction
NSensing input
Voltage: 95~132VAC or 190~264VAC 1 phase, jumper optional
Frequency: 50160 Hz, optional
Output
Voltage: 90 Vdc max @ 207 V AC
Current: 4A continuous, 10A intermittent, 10 seconds duration
Resistance: 15 Ohm minimum
Voltage Regulation
Voltage accumulation: residual voltage at AVR terminals >5 VAC
Thermal drift: AVR 0.05% per change in ambient temperature
External Voltage Regulation: 7% with 1K Ohm 1 Watt Trimmer
Unit power: 10 watts maximum
Under frequency protection: setpoint, 95% Hz
UFRO: Slope 170% down to 30 Hz
Soft start ramp time: 2 seconds
