Genie single axis Joystick controller
Parts No: 101175GT
Used for Z60-34、Z80-60、Z45-25、Z135-70、S80、S85、S125.....
Specifications
Lenght (mm)145
Width (mm)70
Height (mm)70
Weight (kg)0.46
Product Features
Hall-effect angle detection, long life
Spring return
Various output voltage range optional
Various handle optional
Technical Information
Mechanical features
Travel angle ±18°
Operating type Spring return
Breakout force 9N
Operating force(max) 18N
Maximum allowable force >300N
Expecting life >5 million cycles
Weight 420g(without handle)
Electrical data
Power supply 5.0±0.5Vdc

Power supply current

Maximum allowance overload voltage 30Vdc
Reverse polarity voltage(max) -15Vdc
Output linearity tolerance
Analog rocker switch power supply 5.0±0.5Vdc
Analog rocker switch output voltage 1.15V~2.5V~3.85V
Load capacity 1A@28Vdc
Button switch
Mechanical life >1million times
Environmental data
Operating temperature -30℃~+70℃
Storage temperature -40℃~+85℃
Protection level IP67
